Thread Gages

Working Thread Plug, Thread Ring and Thread Setting Plug Gages are manufactured to inspect the Pitch Diameter and the Functional Thread. Thread gages are used to ensure the assembly of mating parts. Unified Inch standard gages are manufactured per ASME B1.2. M Series Metric thread gages are manufactured per ASME B1.16M. Standard thread gages are made to a Class X tolerance. Gages may be purchased individually or as assemblies. Plug gage assemblies are marked with the thread size, class of fit and pitch diameters. Pipe Gages per ASME B1.20.1,  ASME B1.20.5 and Hole Location gages stocked. ACME, Buttress, STI and gages for other custom thread forms are also available.
